main feature:
1. Directly display the test hardness value through the 5.5-inch LCD touch screen;
2. Through the built-in system, the hardness value error can be electronically debugged, and the adjustment range is between 95% and 105%.
3. The shell is molded and casted by a special foundry process, the structure is stable and not deformed, and can work in a relatively harsh environment; the car paint is of high grade and has strong scratch resistance, and it is still bright as new after many years of use;
Applications:
Casting and forging parts Sample testing and acceptance inspection
Flat and cylindrical workpieces Steel, non-ferrous metals.
Automotive and aviation industries Carbide, ceramics, stainless steel
Labs and workshops
Main technical specifications：
MODEL | MHRS-150 |
Measuring range | 20-88HRA\20-100HRBW\20-70HRC |
Test force | 8.4\980.7\1471N(60\100\150Kgf) |
Maximum allowable height of sample | 230mm |
Distance from the center of the pressure head to the machine wall | 165mm |
Hardness resolution | 0.1HR |
Dimensions | 522x293x729 mm |
weight | 98Kg |
power supply | AC220V50Hz |
Standard configuration：
Daping workbench: 1
Xiaoping workbench: 1
V-shaped workbench: 1
Steel ball indenter 1/16”: 1 piece
Diamond indenter: 1
Standard Rockwell hardness blocks: HRA,
HRBW, HRC
