main feature:
Lever loaded, accurate, reliable, durable, high testing efficiency;.
HRD-45 type HRN, HRT scales (other surface Rockwell scales can be selected);
The test process is automated, without human error;
The accuracy complies with GB/T230.2, ISO6508-2 and American ASTM E18 standards.
Applications:
HRD-45 measures the surface Rockwell hardness of ferrous metals, alloy steels, hard alloys and metals after surface treatment such as nitriding, cyaniding, carburizing and electroplating.
Main technical specifications：
Measuring range | 70-94HR15N，42-86 HR30N,20-77 HR45N， 60-93 HR15T，29-82 HR30T,10-72 HR45T. |
Test force | 147.1,294.2,441.3N，（15,30,45kgf） |
Maximum allowable height of sample | 170mm; |
Distance from the center of the pressure head to the machine wall | 135mm; |
Hardness resolution | 0.5HR； |
Dimensions | 466x238x630mm; |
weight | 约65kg |
Standard configuration:
Daping test bench: 1
Xiaoping test bench: 1
V-type test bench: 1
1/16″steel ball indenter: 1
Diamond indenter: 1
HRD-45 standard surface Rockwell hardness block: 4 pieces
