main feature:
It has the function of power-on self-inspection, the function of restoring the factory parameters, and the function of automatic shutdown in 5 minutes; it adopts dot-matrix LCD (128×64) full Chinese display, and is not affected by voltage fluctuations; it adopts two operation modes: direct mode and menu mode; with software Calibration function to ensure measurement accuracy; the host can be equipped with 7 different impact devices, which can automatically identify the type of impact device; large-capacity memory can store 500 sets (up to 13,000 single measurement values) of data.
Applications:
Hardness testing of products during mass production; hardness testing of annealing, tempering, quenching and other heat treatments; on-site hardness testing of mechanical permanent assembly parts after installation; hardness testing of heavy workpieces, mold steel, bearings, gears, etc.; Failure analysis of pressure vessels, turbogenerator sets and their equipment.
Main technical specifications:
Measuring range: 150-960HLD; 17.68.5HRC; 19-651HV; 30-100HS; 59-851HB; 13-100HRB
Test direction: 360°;
Test materials: 10 kinds;
Hardness conversion: HL, HRC, HRB, HRA, HB; HV; HS;
Working voltage: 3.3V;
Continuous working time: about 1000H (without backlight);
Communication interface standard: USB;
Overall dimensions: 136*70*20mm;
Weight: about 0.2kg (host)
Standard configuration: D-type impact device: 1 small support ring: 1 standard Leeb hardness block: 1 charger: 1 adhesive: 1 bottle
