main feature:
Novel shape, solid structure, high test efficiency; automatic loading, closed-loop control series, LCD screen display during the test process; on-board measurement, can convert Rockwell, Vickers hardness value and tensile strength, random print hardness measurement results; large LCD liquid crystal Display screen, menu intelligent prompt, easy to operate; optional video system, CCD image processing system; precision conforms to GB/T231.2 ISO6506-2 and American ASTM E10 standards. .
Applications:
Determination of Brinell hardness values of ferrous metals, non-ferrous metals and bearing alloy materials; a wide range of applications, especially for precision measurement of parallel planes.
Main technical specifications:
Brinell scale: HBW2.5/62.5, HBW2.5/187.5, HBW5/125, HBW5/750, HBW10/100, HBW10/1500, HBW10/3000, HBW10/250, HBW10/500, HBW10/1000
Test force: 2.5kgf(612.9N), 100kgf(980.7N), 125kgf(1226N), 187.5kgf(1839N), 250kgf(2452N), 500kgf(4903N), 750kgf(7355N), 1000kgf(9807N), 1500kgf(14710N ), 3000kgf (29420N)
The maximum height of the test piece: 225mm; dwell time: 5~60s
Hardness test range: 8~650HBW Optical magnification: 20X
Distance from the center of the indenter to the body: 135mm Power supply: AC220+5%, 50~60Hz
Dimensions (mm): 565*236*786mm Host weight: 130kg
Standard configuration: large flat test bench: 1; small flat test bench: 1; V-type test bench: 1
Tungsten carbide ball indenter: 1 piece each for φ10/φ5/φ2.5mm
Standard Brinell hardness block: 2 pieces
