main feature:
Lever loading, convenient operation, stable test accuracy, accuracy, reliability, durability, and high test efficiency; Electronic reversing switch; high-precision reading microscope measurement system; Widely applicable to quality monitoring in production sites, with strong adaptability to the working environment; Accuracy conforms to B/T231.2 ISO6506-2 and American ASTM E10 standards.
Applications:
Determination of Brinell hardness of ferrous metals, non-ferrous metals and bearing alloy materials; wide range of applications, suitable for precision measurement of parallel planes, and stable and reliable measurement of curved surfaces.
Main technical specifications:
Measuring range: 8-650HBW;
The maximum allowable height of the sample: 230mm;
Test force: 1838.8; 2451.8; 4903.5; 7355.3; 9807; 29421N
（187.5; 250; 500; 750; 1000; 3000kgf）
Distance from the center of the pressure head to the machine wall: 120mm;
Minimum detection unit: 1um;
Power supply: AC220V50/60Hz;
Dimensions: 660x500x1000mm;
Weight: about 210kg
Standard configuration:
Daping workbench: 1
Xiaoping workbench: 1
V-shaped workbench: 1
Tungsten carbide ball indenter: Φ2.5 Φ5 Φ10
Standard Brinell hardness block: 2 pieces 20x reading microscope: 1 piece
